| Business Type | Manufacturer, Supplier |
| Brand Name | Himakshi |
| Country of Origin | India |
| Application | Road Construction |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Automation Grade
Semi-automatic
Material
Mild Steel
Width
2.4 Mtr. Standard
Adjustment Width
2.4 Mtr. to 3.8 Mtrs. with Extension Bar By Clossing of Nozzle.
Nozzle Distance
225 mm Nozzle c/c.
Controlling of Spray Bar
Pneumatic Operation of Nozzle
Preheating of Spraybar
By Full Circulation of Preheated Bitumen.
Air Pressure Gauge
0-10Kg./ Cm2
If you dream about getting educated from one of the top universities then definitely check these series of programs. Learn from the experts and faculty who are always engaged in teaching and research to push the boundaries.
BITUMEN PUMP
2" x 2" Size Positive displacement Gear Pump with output 350 liters/min. (Max.)
DRIVING UNIT
Kirlosker/HTC Vertical air Cooled diesel engine.
OPERATOR PLATFORM
Techometer : Slow Speed 0.5 Metre /min.
AIR COMPRESSOR
Make - ELGI/INDOAIR 2 CYL, 3H. P. Working
Pressure 9kg/cm2 13.25 M3, Capacity 360 L.P.M. 550 R.P.M.
BITUMEN SPRAYING PRESSURE
0 To 6 Kg/cm2.
TEMPERATURE GAUGE
0-250c at Front of Tank
TECHNICAL SPECIFICATIONS
| MODEL | ATM - 5000 | ATM - 6000 | ATM - 7000 |
| Length | 2500mm. | 3100mm. | 3300mm. |
| Width | 1800mm. | 1900mm. | 1900mm. |
| Height | 1500mm. | 1550mm. | 1650mm. |
| Capacity | 4000Ltrs. | 6000Ltrs. | 7000Ltrs. |
| Man Hole | 600mm. | 600mm. | 600mm. |
| Insulation | 50mm. | 50mm. | 50mm. |
| Fuel Consumption of Burner | 20 Ltrs | 20 Ltrs. | 20 Ltrs. |
| Burner | Compressed air type | Compressed air type | Compressed air type |
| Mounting | Ashok Leyland or Tata | Ashok Leyland or Tata | Ashok Leyland or Tata |
| Wheel Base | 176"/166" | 176"/166" | 176"/166" |
| Bitumen Tank Shape | Ovel Shape | Ovel Shape | Ovel Shape |
